Rear suspensionbrackets installation
WARNING
1.
Thevehiclemust be
immobilized
, the
engine turnoff
and cooled.
2.
Alwayswear
safetyglasses
during installation, adjustment or repair.
3.
Please readandensure you
haveunderstood thewarnings
andguidelines.
4.
Make sure the vehicle is
safelysecured inplace
bya systemdedicated to this use (jack stands andhoist) and that it is supportedor
fixedon its locations that arenot likely tobreak, bendor slip. Ahydraulic jack is not safe; nor is a log. The vehiclemust benot able to
move.
The installation requires that the vehicle is in two-wheel drivemodewith thegearbox inneutral. After lifting the vehicle
and removing thewheels:
1) On the vehicle, unbolt theoriginal nut
BB
and remove theoriginal bolt
AA
of the suspensionbracket. Keep them for
a later reinstallation. See
figure4.
2) Position the rear-right suspensionbracket inplaceand fix it using theM10-1.5 x140-mmbolt
02
and theM10-1.5
nylonnut
05
.
3) Place theM8U-bolt
03
and fix it inplaceusinganM8 flatwasher
06
(place thewasher on theoblonghole side) and
the two (2)M8-1.25nylonnuts
04
.
Front of theATV
Fig. 4
