5/5
ATV
INSTALLATIONMANUAL
FRONTANDREARMOUNTINGBRACKETKIT
KIMPEXN
°
375910
FORCOMMANDERTRACKSYSTEMANDBRUTEFORCE650i/750i VEHICLE
KIMPEX INC.
/ 5355, rue St-Roch /Drummondville (Québec) Canada / J2B6V4
KIMPEXUSA
/ 100Walnut Street /Champlain (NewYork) / 12919
2810495
•
A-2810495-EN-reva
•
LithographiéauCanada / Litho’d inCanada
5
4) Tightenall bolts inplace.
WARNING
1.
Donot overtorque thebolts. Somepartsmaybe subject todeformation. If thebolts are too tight, some safetyaspects couldbe
compromised.
2.
Be careful: an incorrectlypositioned suspensionbracket couldgive someplay,whichcouldmakedriving riskier aswell as lead to
breakage to thevehicle, a loss of control and serious injuries.
MountingHoleson theHubof theTrackSystem
To install your track system, use theholes indicated (see
figure6
) anddonot forget to install the SHIMbefore the
installationof themainaxle. See
figure7
.
CAUTION
: Use the chromedwheel nutsNo. 015696 supplied to replace theoriginalwheel nuts of the vehicle.
Fig. 6
Fig. 5
Front of theATV
Fig.
