2/5
ATV
INSTALLATIONMANUAL
FRONTANDREARMOUNTINGBRACKETKIT
KIMPEXN
°
375910
FORCOMMANDERTRACKSYSTEMANDBRUTEFORCE650i/750i VEHICLE
KIMPEX INC.
/ 5355, rue St-Roch /Drummondville (Québec) Canada / J2B6V4
KIMPEXUSA
/ 100Walnut Street /Champlain (NewYork) / 12919
LithographiéauCanada / Litho’d inCanada
•
2810495
•
A-2810495-EN-reva
2
FRONTA-ARMBRACKETS
REARSUSPENSIONBRACKETS
Ref. Description
ItemN
o
Qty Ref. Description
ItemN
o
Qty
1
FronttA-armbracket
2810444-1-1000
2
1
Rear-left suspensionbracket
2810444-4-1000
1
2
Front-left clampingplate
2810444-2-2000
1
Rear-right suspensionbracket
2810444-3-1000
1
Front-right clampingplate
2810444-1-2000
1
2
M10-1.25 x140mmCl.8.8bolt
S1111-100A4-0D1
1
3
M12-1.75 x70mmCl.8.8
Carriagebolt
S2411-M1270-031
1
3
M8-1.25 x34mmCl.8.8U-bolt
S2213-J4461-002
1
4
M12-1.75Cl.8.8Nylonnut
S4186-M120P-021
1
4
M8-1.25Cl.8.8Nylonnut
S4186-M080M-021
2
5
M12Flatwasher
S4612-M1200-0A1
1
5
M10-1.5Cl.8.8Nylonnut
S4186-M100N-021
1
6
SHIM
2810159-7000
8
6
M8Flatwasher
S4612-M080-0K1
1
7
M10-1.25Chromedwheel nut
0156969
8
7
SHIM
2810159-7000
8
8
M10-1.25Chromedwheel nut
015696
8
Fig. 1
