2/7
ATV
INSTALLATIONMANUAL
FRONTANDREARMOUNTINGBRACKETKIT
KIMPEXN
o
375913
FORCOMMANDERTRACKSYSTEMANDHONDATRX420RIGID (2014)ANDFOREMAN (2014)VEHICLES
KIMPEX INC.
/ 5355, rue St-Roch /Drummondville (Québec)Canada / J2B6V4
KIMPEXUSA
/ 100Walnut Street /Champlain (NewYork) / 12919
LithographiéauCanada / Litho’d inCanada
2810503
A-2810503-EN
2
FRONTA-ARMBRACKETS
REARSUSPENSIONBRACKETS
Ref. Description
ItemN
o
Qty Ref. Description
ItemN
o
Qty
1
Front-rightA-armbracket
2810435-1-1000
1
1
Rear suspensionbracket
2810503-3-1000
1
Front-leftA-armbracket
2810435-2-1000
1
2
M12-1.75 x30mmCl.8.8bolt
S1111-12030-0D1
2
2
M8 - 1.25 x71mmCl.8.8U-bolt
S2213-J3671-002
1
3
M8-1.25 x61mmCl.8.8U-bolt
S2213-J4461-002
2
3
M8 - 1.25 x61mmCl.8.8U-bolt
S2213-J4461-002
2
4
M8-1.25Cl.8Nylonnut
S4186-M080M-021
4
4
M8 - 1.25Cl.8.8Nylonnut
S4186-M080M-021
6
5
M12-1.75Cl.8Nylonnut
S4186-M120P-021
2
5
M8Flatwasher
S4612-M0840-0K1
4
6
M8Flatwasher
S4612-M0840-0K1
4
Fig. 1
