3/7
ATV
INSTALLATIONMANUAL
FRONTANDREARMOUNTINGBRACKETKIT
KIMPEXN
o
375913
FORCOMMANDERTRACKSYSTEMANDHONDATRX420RIGID (2014)ANDFOREMAN (2014)VEHICLES
KIMPEX INC.
/ 5355, rue St-Roch /Drummondville (Québec)Canada / J2B6V4
KIMPEXUSA
/ 100Walnut Street /Champlain (NewYork) / 12919
2810503
A-2810503-EN
LithographiéauCanada / Litho’d inCanada
3
FrontA-armbracket Installation
WARNING
1.
Thevehiclemust be
immobilized
and the
engine turnedoff
andcooled.
2.
Alwayswear
safetyglasses
during installation, adjustment or repair.
3.
Please readandensure you
haveunderstood thewarnings
andguidelines.
4.
Make sure the vehicle is
safely secured inplace
bya systemdedicated to this use (jack stands andhoist) and that it is supportedor
fixedon locations that arenot likely tobreak, bendor slip. Ahydraulic jack is not safe; nor is a log. The vehiclemust benot able tomove.
The installation requires that the vehicle is in two-wheel drive
modewith thegearbox inneutral. After lifting the vehicleand
removing thewheels:
1)
Remove theuniversal joint guard. Keep theparts for later
reinstallation.
2)
Insert theM12-1.75 x 65mm carriagebolt
G
in thehole
identifiedby a label on theA-armbracket
01
. In the
packaging, this bolt ismountedon the rodend
M
of the
front anti-rotationarm.
3)
Lean theA-armbracket
01
under the suspensionarm
taking care that the suspensionarm tubes are firmly
presseddownon thehalf-moon supports of theA-arm
bracket. SeeFigure2.
4)
FixeachU-bolt
02
and
03
inplaceusing the six (6)
M8-1.25nylonnuts
04
and the four (4) flatwashers
05
(place thewasher on theoblonghole side)
.
SeeFigure3.
5)
Tightenall bolts inplace.
Fig. 2
Front of theATV
Fig. 3
Front of theATV
