6/7
ATV
INSTALLATIONMANUAL
FRONTANDREARMOUNTINGBRACKETKIT
KIMPEXN
o
375913
FORCOMMANDERTRACKSYSTEMANDHONDATRX420RIGID (2014)ANDFOREMAN (2014)VEHICLES
KIMPEX INC.
/ 5355, rue St-Roch /Drummondville (Québec)Canada / J2B6V4
KIMPEXUSA
/ 100Walnut Street /Champlain (NewYork) / 12919
LithographiéauCanada / Litho’d inCanada
2810503
A-2810503-EN
6
WARNING
1.
Donot overtorque thebolts. Somepartsmaybe subject todeformation. If thebolts are too tight, some safetyaspects couldbe
compromised.
2.
Be careful: an incorrectlypositioned suspensionbracket couldgive someplay,which couldmakedriving riskier aswell as lead to
breakage to thevehicle, a loss of control and serious injuries.
MountingHoles in theHubof theTrackSystem
To install your track system, use theholes indicated in the following figure.
Fig. 9
