5/7
ATV
INSTALLATIONMANUAL
FRONTANDREARMOUNTINGBRACKETKIT
KIMPEXN
o
375913
FORCOMMANDERTRACKSYSTEMANDHONDATRX420RIGID (2014)ANDFOREMAN (2014)VEHICLES
KIMPEX INC.
/ 5355, rue St-Roch /Drummondville (Québec)Canada / J2B6V4
KIMPEXUSA
/ 100Walnut Street /Champlain (NewYork) / 12919
2810503
A-2810503-EN
LithographiéauCanada / Litho’d inCanada
5
5)
Fasten the front part of the rear suspension
bracket
02
using two (2)U-bolts
07
, four (4)
M8-1.25nylonnuts
09
and four (4)washers
11
.
SeeFigure6.
6)
Fasten the rear part of the rear suspension
bracket
02
through the frameof the vehicle
using two (2)M12-1.75bolts
04
and two (2)
M12-1.25nylonnuts
10
. SeeFigure7.
7)
Tightenall bolts inplace.
It is suggested to cut the fender soas to
avoidany interferencewith the track. See
Figure8.
Fig. 7
Front of theATV
Fig. 6
Front of theATV
Fig. 8
