7/7
ATV
INSTALLATION MANUAL
ANTI-ROTATION ARMS SET
KIMPEX N
°
375928
FOR COMMANDER WTX TRACK SYSTEM. RIGID VEHICLES SUSPENSION
KIMPEX INC.
/ 5355, rue St-Roch / Drummondville (Québec) Canada / J2B 6V4
KIMPEX USA
/ 100 Walnut Street / Champlain (New York) / 12919
2810479-00-13
•
A-2810479-00-13-EN
•
Lithographié au Canada / Litho’d in Canada
7
b. Place the rear anti-rotation arm bracket
01
over the hex bolts.
16
and fasten using the existing nuts
23
removed
in
step a
. See
figure 5
.
NOTE : Original washers
27
, removed in step a, are not necessary. See figure 5.
c.
Finish the assembly using the hex bolt.
03
, the flat washer
05
and the nut
04
.
NOTE : Refer to the track kit manual for torque specifications and complete the installation.
3) Insert the anti-rotation arm into the hole of the rear anti-rotation arm bracket
01
, already installed. See
figure 5.
4) Replace the components removed in
step 1
in the same order illustrated in
figure 6
and
figure 4
.
Fig. 6
Front of the ATV
