4/7
INSTALLATION MANUAL
ANTI-ROTATION ARMS SET
KIMPEX N
°
375928
FOR COMMANDER WTX TRACK SYSTEM. RIGID VEHICLES SUSPENSION
KIMPEX INC.
/ 5355, rue St-Roch / Drummondville (Québec) Canada / J2B 6V4
KIMPEX USA
/ 100 Walnut Street / Champlain (New York) / 12919
Lithographié au Canada / Litho’d in Canada
•
2810479-00-13
•
A-2810479-00-13-EN
4
SPARE PARTS
Description
Ref.
Ref.
No. of included
item
Quantity
Qty /ATV
Item No. to order
Figure 1 Figure 2
Rep. Set Front Anti-rot
D
7810304-2000
1
2
2810304-20E
E
Q2212-10082
1
F
S1711-00630-052
1
I
S4186-10600-022
1
K
S4612-00600-0S1
1
L
S4614-00600-082
2
Hardware set front rod-end
A
2510039-1-20-2000
1
2
7810479H-1
B
2510039-1-20-4000
1
G
S2411-M1265-031
1
J
S4186-M120P-021
1
M
S9113-C0500-002
1
N
7S4612_M1800_0B1
1
Rubber and slider
H
7990163-3-2000
2
2
7990163-40
J
7990163-1-3000
1
M
S4186-M160Q-051
1
SYMBOLS USED
WARNING
These boxes warn about wrong behaviour that can lead to serious injury or death.
CAUTION
: These paragraphs indicate wrong behaviour that can cause minor injuries or broken equipment.
This logo indicates operating tips allowing maximum use and lifespan of your product.
These labels are visible on the frame and brackets, and indicate where the tracks are placed:
front left, front right, rear left, rear right.
These indicate that the bolt
A
must be installed in its socket before the installation of the
mounting brackets on the vehicle.
Yellow Red Green Blue
