ATV
INSTALLATION MANUAL
FRONT AND REAR MOUNTING BRACKET KIT
KIMPEX N
°
375911
FOR COMMANDER TRACK SYSTEM AND POLARIS SPORTSMAN 95-04 VEHICLES
KIMPEX INC.
/ 5355, rue St-Roch / Drummondville (Québec) Canada / J2B 6V4
KIMPEX USA
/ 100 Walnut Street / Champlain (New York) / 12919
Lithographié au Canada / Litho’d in Canada
•
2810496
•
A-2810496-EN
2
FRONT A-ARM BRACKETS
REAR SUSPENSION BRACKETS
Ref. Description
Item N
o
Qty Ref. Description
Item N
o
Qty
1
Clamping block
2510039-1-20-1000 1
1
Rear-left suspension bracket
2810153-4000
1
2
Main axle adapter
2810153-5000
1
Rear-right suspension bracket
2810153-3000
1
3
Front-left A-arm bracket
2810174-2000
1
2
Main axle adapter
2810153-5000
1
Front-right A-arm bracket
2810174-1000
1
3
Rear suspension bracket guide
2810153-8000
1
4
Front-left clamping plate
2810174-4000
1
4
3/8"-24 "T" nut
2810153-9000
4
Front-right clamping plate
2810174-3000
1
5
9/16" DE x 0.397" DI x 3/8" spacer
Q2212-10067
2
5
Additional main axle adapter
2810174-5000
1
6
5/16"-18 x 2-3/4" U-bolt
S2215-D1639-002
1
6
3/8"-24 "T" nut
2810174-6000
4
7
1/4"-20 x 3/4" carriage bolt
S2412-0C012-0A2
2
7
3/8"-16 x 1-3/4" hex. bolt
S1711-00614-052
2
8
3/8"-16 x 1-1/2" carriage bolt
S2412-0E024-0A2
2
8
3/8"-16 x 2" hex. bolt
S1711-00616-052
1
9
3/8"-16 X 3-1/2"
Allen socket machine screw
S3161-B0D36-000
2
9
3/8"-16 X 3-1/2"
Allen socket machine screw
S3161-20D56-050
2
10
1/4"-20 Nylon nut
S4186-10400-022
2
10
3/8"-16 Nylon nut
S4186-10600-022
5
11
5/16"-18 Nylon nut
S4186-10500-022
2
12
3/8"-16 Nylon nut
S4186-10600-022
2
13
5/16" flat washer
S4612-00500-002
2
14
3/8" flat washer
S4612-00600-002
2
Fig. 1
