ATV
FRONT AND REAR A-ARM BRACKET KIT
FOR ST-90 TRACK KIT
FRONT LEFT AND RIGHT A-ARM BRACKET
Ref. Description
Item Number
Qty
1
Long Ball Joint Spacer
2510039-1-20-2000
2
2
Short Ball Joint Spacer
2510039-1-20-4000
2
3
M12-1.25 T-Nut
6020238-1000
8
4
Front Anti-rotation Assembly
2810304-10A
2
5
M12-1.25 X 35 mm Wheel Stud
S2512-01235-052
8
6
Tightening Front Plate
6020177-1-2000-511 2
7
Wheel Spacer
6020177-1-4000-511 2
8
Front Right A-arm Bracket
6020177-1-1000-511 1
Front Left A-arm Bracket
6020177-2-1000-511 1
9
Neoprene Flat Washer
7810304-2000
2
10
9/16” O.D. X .44” Tightening Sleeve
Q2212-10082
2
11
3/8” nc X 3-3/4” Hex Bolt
S1711-00630-052
2
12
5/16” nc X 2” Hex Bolt
S1711-00516-052
12
13
1/2” nc X 3” Carriage Bolt
S2412-0G048-0A2
2
14
1/2” nf Thin Nut
S4116-20800-022
2
15
3/8” nc Nylock Nut
S4186-10600-022
6
16
1/2” nc Nylock Nut
S4186-10800-022
2
17
3/8” dia Flat Washer
S4612-00600-0S1
2
18
1/2” nf Ball Joint
S9113-C0500-002
2
19
Tightening Plate
6020177-1-5000-511 2
20
3/8” nc X 2-1/4” Carriage Bolt
S2412-0E036-0A2
4
21
5/16” nc Nylock Nut
S4186-10500-022
12
22
Front Right Limiter Plate
6020177-5-1000-511 1
Front Left Limiter Plate
6020177-6-1000-511 1
23
M12 X 80 mm Hex Bolt
S1111-12080-0F1
2
24
Tightening Spacer
6020177-5-2000-511 2
25
3/8” dia Flat Washer
S4612-00600-002
4
26
M12 Nylock Nut
S4186-M120-021
2
KIMPEX N°
374502
|
