9/15
ATV
FRONT AND REAR A-ARM BRACKET KIT
FOR ST-90 TRACK KIT
REAR LEFT AND RIGHT A-ARM BRACKET
Ref. Description
Item Number
Qty
1
Rubber Bushing
2510039-1-30-6000
6
2
Bushing Spacer Tube
2510039-3-20-2000
2
3
M12-1.25 T-Nut
6020238-1000
8
4
M12-1.25 X 35 mm Wheel Stud
S2512-01235-052
8
5
Wheel Spacer
6020177-1-4000-511 2
6
Rear A-arm Clamping Plate
6020177-3-2000-511 2
7
Rear Tightening Support
6020177-3-3000-511 2
8
Rear Left A-arm Bracket
6020177-4-1000-511 1
Rear Right A-arm Bracket
6020177-3-1000-511 1
9
Rear Anti-rotation Tube
7810304-30-1000
2
10
Tightening Sleeve
Q2212-10093
2
11
3/8” nc X 4-1/4” Hex Bolt
S1711-00634-052
2
12
3/8” nc X 1-1/2” Carriage Bolt
S2412-0E024-0A2
4
13
3/8” nc X 2-1/2” Carriage Bolt
S2412-0E040-0A2
4
14
5/8” nc Nut
S4111-11000-022
2
15
3/8” nc Nylock Nut
S4186-10600-022
12
16
5/8” nc Nylock Nut
S4186-11000-022
2
17
3/8” dia Flat Washer
S4612-00600-0S1
6
18
3/4” I.D. X 2” O.D. X 1/8” Flat Washer
S4612-01200-022
2
19
50 mm O.D. X 17 mm I.D. X 3 mm Flat Washer S4612-M1600-01W
4
20
3/8” nc X 1-1/2” Hex Bolt
S1711-00612-052
2
21
Flat Washer
2810371-3-6000
2
KIMPEX N°
374502
|
