5/5
ATV
INSTALLATION MANUAL
FRONT AND REAR MOUNTING BRACKET KIT
KIMPEX N
°
375912
FOR COMMANDER TRACK SYSTEM AND KING QUAD 500/750 VEHICLES
KIMPEX INC.
/ 5355, rue St-Roch / Drummondville (Québec) Canada / J2B 6V4
KIMPEX USA
/ 100 Walnut Street / Champlain (New York) / 12919
2810498
•
A-2810498-EN
•
Lithographié au Canada / Litho’d in Canada
5
4) Tighten all bolts in place
WARNING
1.
Do not overtorque the bolts. Some parts may be subject to deformation. If the bolts are too tight, some safety aspects could be
compromised.
2.
Be careful: an incorrectly positioned A-arm bracket could give some play, which could make driving riskier as well as lead to breakage to
the vehicle, a loss of control and serious injuries.
Mounting holes on the hub of the track system
To install your track system, use the holes indicated in the following figure.
Fig. 5
Fig. 6
